Description
Klein Tools CL490 Dual Display Clamp Meter is auto-ranging for precise measurements with a secondary display for easier viewing in tight spaces. The meter reads AC/DC current, voltage, resistance, continuity,frequency, and capacitance; all with True RMS accuracy. It features diode testing and temperature is taken, via thermocouple. There is NCV detection with audio-visual alerts for additional functional applications. To ensure visibility in any lighting, there is a backlit and hi-vis display.
Includes:
- 1 x Clamp Meter
- 1 x Carrying Case
- 1 x Test Leads
- 1 x Thermocouple
- 2 x AA Batteries
Features:
- Dual Display digital clamp meter allows users to see readings in tight space areas
- AC/DC clamp meter with True RMS provides accurate and reliable measurements across various applications
- Measures AC/DC current and NCVT via clamp; AC/DC voltage, resistance, continuity, frequency/duty cycle, DC microamps, diode test and capacitance via test leads; temperature via thermocouple
- Backlit reverse-contrast LCDs for clear data and best view-ability in all environments
- Withstands drops from 6.6 feet (2 m), and includes right-angle input test leads, thermocouple, storage pouch, instruction manual, and 2 x AA batteries
- Ergonomic design provides a comfortable grip, with easy dial adjustment using the thumb
- Non-contact voltage detection is integrated into the clamp jaw, with audible and visual indicators that intensify as the clamp moves closer to the voltage source
- Clamp body includes a side-mounted test lead holder and a back mount that accommodates an optional magnetic hanger (Cat. Nos. 69445 or 69417) for hands-free operation
Specifications:
- Type: Dual Screen AC/DC Current TRMS Clamp
- Application: Measures AC/DC Current and NCVT via the Clamp and AC/DC voltage, DC Microamp Current, Resistance, Continuity, Frequency, Duty-Cycle, Capacitance and Tests Diodes via the Test Leads, and Temperature with Thermocouple
- Special Features: Bottom Display; Automatically Ranging; TRMS Measurement; AC/DC Current Measurement; High Visibility Reverse Contrast LCD; NCVT
- Material: ABS/Electronics
- Auto-Power Off: Yes, Unless Disabled on Startup
- Jaw Size: 41mm (1.6”)
- Drop Protection: 2m (6.6″)
- Display: 4000 Count Backlit, Hi-Viz
- Display Size: Main Display: 1.54” x 0.86” (3.9 cm x 2.2 cm) Secondary: 1.04” x 0.72” (2.6 cm x 1.8 cm)
- Functions: TRMS, AC/DC Current, NCVT, AC/DC Voltage, Resistance, DC microamp, Frequency, Capacitance, Continuity, Duty Cycle, Diode Test, and Temperature
- Auto Ranging: Yes
- TRMS: Yes
- Voltage: 600V AC/DC
- Frequency: 10Hz – 60kHz
- Current: 400A AC/DC
- Capacitance: 4000µF
- Ohms (Resistance): 40MΩ
- AC Voltage: 600V
- DC Voltage: 600V
- DC Polarity Indicator: Yes
- DC Micro-Amp: 200µA
- Temperature Range: -40° to 1832°F (-40° to 1000°C)
- Accuracy: ± (% of Reading + # of Least Significant Digits) Refer to Manual for Accuracy Depending on Active Function Selection Values Stated at 65° to 83°F (18° to 28°C)
- Standard: CATIII 600V, Class 2, Double Insulation Safety Rating IEC EN 61010-1, 61010-2-032. IEC EN 61326-1, 61326-2-2.Conforms to UL STD.61010-1, 61010-2-032;Certified to CSA STD.C22.2 NO. 61010-1, 61010-2-032
- Dimensions (L x W x H): 320mm x 76mm x 146mm
- Weight: 0.6kg
