Klein 3006CR Ratcheting Non-Insulated Terminal Crimper, 10 to 22 AWG Wire

Description

The full-cycle Ratcheting Crimper crimps 10-22 AWG non-insulated wire terminals. This tool features five crimping cavities in one tool for five size ranges of non-insulated terminals. Crimper design provides low effort to crimp while maintaining a high terminal pull-off force. Built-in ratchet ensures full-cycle crimping for a uniform crimp every time. Compound lever-action of narrow-span handles puts more crimping power into each squeeze. Comfort grips help reduce hand fatigue.

Features:

• Crimping Tool crimps non-insulated terminals onto 10-22 AWG stranded copper wire
• Adjustable compound action design puts more crimping power into each squeeze
• Five crimping cavities in one tool: 22–18 AWG, 18–14 AWG, 14-12 AWG, 12-10 AWG and 10 AWG terminals
• Built-in ratchet ensures full-cycle crimping for a uniform crimp every time
• Unique cavity design provides consistent crimp from either side of the tool
• Dial adjusts the amount of force applied to the crimp
• Dual-material molded grips provide added comfort

Specifications:

• Type: Ratcheting Crimper
• Application: Non-Insulated Terminal Crimping on Stranded Wire
• Special Features: 4 Crimping Cavities
• Material: Steel
• Handle Color: Red/Black
• Handle Finish: Dual-Material
• Cable Size: 10-22 AWG
• Connector Type: Non-Insulated
• Dimensions (L x W x H): 229mm x 76mm x 2mm
• Weight: 0.6kg
