Cigweld W1008140 (WeldSkill 140) 140A Stick & Lift TIG Multi Process Inverter Welder

Description

The WeldSkill 140 is a single phase welding inverter with a user-friendly control panel, practical push button operation for mode selection, clearly visible LED indicators and sturdy large control knob.

Compact and light-weight, this unit is a great addition to the shed ensuring the ultimate portability for the Home Handyman, Tradesman, Farmer or Maintenance Worker.

In addition to its appealing design and functional features, the WeldSkill 140 provides the added reassurance of a high quality welding inverter that complies to Australian Standards. Simply plug it in at home or into any standard 10 Amp power point and get welding right away!

Features:

• 240 Volt, 10 Amp Supply Lead & Plug Fitted to Power Source
• Fully compliant to AS 60974.1-2006
• Max. Electrode Size 3.2mm. Suitable for All Electrode Types Except AWS E6010 Cellulose
• Over Temperature Cut Out Protection has been fitted to Power Source
• Anti Stick. Helps to prevent the stick electrode from sticking to the work piece
• Hot Start. Improves the arc start characteristics of stick electrodes
• Arc Force. Assists when stick welding in a tight corner or joint fit-up
• Current Range for this Power Source is 10A to 140A of DC Welding Output
• DC Lift TIG function. Provides smooth starting and running characteristics across a broad range of applications
• Rugged case with carry handle and carry strap
• 4m Long Electrode Holder & Work Leads
• Twistlock Electrode Holder. Allows the electrode to be locked securely in place

Specifications:

• Nominal Supply Frequency: 50/60Hz
• Nominal Supply Voltage: 240V AC ± 10%
• Cooling: Fan Cooled
• Australian Standard: AS 60974.1-2006 / IEC 60974-1
• Number of Phases: Single Phase
• Welding Current Range: 10 – 140A
• Nominal DC Open Circuit Voltage: 80V
• Factory Fitted Supply Plug Rating: 10Amps
• Effective Input Current (I1eff ): 10Amps
• Maximum Input Current (I1max): 26.3Amps
• Minimum Single Phase Generator Recommendation: 6.0kW (7.5kVA @ 0.8PF)
• STICK (MMAW) Welding Output, 40ºC, 10 min: 140Amps @ 15% Duty Cycle
• TIG (GTAW) Welding Output, 40ºC, 10 min: 140Amps @ 35% Duty Cycle
• Protection Class: IP21S
• Dimensions (L x W x H): 315mm x 120mm x 200mm
• Weight (without cable): 4.7kg

Warranty:

• 3 Years Warranty on Power Source covered by Cigweld Australia
